The National Annex to Eurocode 7 (BS EN 1997-1:2004) and the UK National Annex for seismic loading (BS EN 1998-5:2004) set the framework for seismic amplification analysis across Britain, but applying these codes in Liverpool requires a deep understanding of the local geology. Much of the city sits on glacial till overlying Triassic sandstones, with thick alluvial deposits along the Mersey valley that can significantly amplify ground motion. For projects near the waterfront or in areas like Toxteth and Everton, where variable drift thickness is common, a site-specific seismic amplification analysis is essential to capture the true dynamic response rather than relying on generic soil factors. Complementing this study with a resistivity survey helps map subsurface stratigraphy, while CPT testing provides continuous profiles of soil stiffness used directly in the amplification models.
A site-specific amplification analysis in Liverpool can increase the design base shear by up to 40% compared to using the generic Eurocode 8 soil factors.
Process overview
In Liverpool, we often see that the glacial till behaves as a relatively stiff medium, but the overlying made ground and soft alluvial clays can create a sharp impedance contrast that amplifies long-period waves. Our seismic amplification analysis follows the NEHRP site classification system (ASCE 7-16) adapted for UK practice, measuring VS30 through MASW or ReMi arrays. We then run equivalent-linear site response analyses in the frequency domain to generate acceleration response spectra and site-specific soil factors (Fa, Fv). For critical structures like the new Royal Liverpool Hospital extension or high-rise residential towers in the Knowledge Quarter, we combine this with a geotechnical study to tie dynamic properties back to static bearing capacity. The deliverable includes shear wave velocity profiles, amplification functions, and design spectra ready for structural engineers to apply in their models.
Technical reference image — Liverpool
Local context
The contrast between the solid sandstone ridge running through the city centre and the soft alluvial deposits of the Mersey floodplain creates a two-speed seismic response. In the Baltic Triangle or along the docks, where up to 10 metres of soft fill and peat overlie stiff till, the amplification can be severe enough to double the spectral acceleration at periods of 0.5–1.5 seconds. Meanwhile, in areas like Woolton or Mossley Hill, where the till is shallow over bedrock, the amplification is far less pronounced. Ignoring this spatial variability in seismic amplification analysis for Liverpool can lead to either grossly conservative designs in the south or dangerously unconservative ones along the waterfront. The 2022 UK Seismic Hazard Map update from BGS confirms that Merseyside falls in a moderate hazard zone, so site-specific analysis is not optional for Category 2 and 3 structures.
Non-invasive surface wave testing using 24-geophone arrays to measure shear wave velocity profiles down to 30–50 metres. We deploy this across Liverpool's brownfield sites and docklands to classify the ground without drilling, ideal for early-stage feasibility studies.
02
Equivalent-Linear Site Response Analysis
Using DEEPSOIL and STRATA software, we run 1D and 2D ground response models that incorporate strain-dependent modulus reduction and damping curves. The output includes design response spectra for the site-specific soil profile, directly compatible with UK structural design codes.
Relevant standards
BS EN 1998-5:2004 (Eurocode 8 – Seismic Design, UK National Annex), NEHRP Recommended Seismic Provisions (2015), ASCE 7-16 Section 11.4 – Site Class and Amplification Factors, BS 5930:2015 – Code of Practice for Ground Investigations
Common questions
How much does a seismic amplification analysis cost in Liverpool?
For a typical residential or mid-rise commercial project in Liverpool, the seismic amplification analysis ranges between £800 and £1,870. This covers the field survey (MASW or ReMi), laboratory correlation, and the site response report. Complex sites with multiple soil layers or deep alluvial deposits may require additional borehole data, which can increase the cost toward the upper end of the range.
What is the difference between VS30 and site class in the UK context?
VS30 is the average shear wave velocity in the top 30 metres of the ground profile, measured directly from surface wave surveys or downhole logging. The site class (A–E in Eurocode 8) is a simplified category derived from VS30 values. In Liverpool, the glacial till typically yields VS30 of 360–500 m/s (Class C), while soft alluvial zones along the Mersey fall in Class D (180–360 m/s). The site class directly controls the amplification factor applied in structural design, but a site-specific analysis replaces those generic factors with custom ones.
When is a site-specific seismic amplification analysis mandatory in Liverpool?
It is mandatory for all structures classified as Consequence Class 2b and above under the UK Building Regulations (Approved Document A), which includes hospitals, schools, high-rise residential towers, and essential infrastructure. Even for Class 2a buildings (offices, retail), the structural engineer may request a site-specific analysis if the ground profile is variable — which it often is in Liverpool due to the glacial till/alluvial interface and extensive made ground from historical industrial use.
